MainCatalogSatellite NavigationSatellite trackersNAVISET GT50

NAVISET GT50. GPS tracker with GSM & Iridium

Print
The newest device
NAVISET GT50
Other photos
  • NAVISET GT50
  • NAVISET GT50
  • NAVISET GT50
  • NAVISET GT50
  • NAVISET GT50
  • NAVISET GT50
Main characteristics
SKU 2088
Vendor Siblink
Category Satellite - Dual-mode trackers
Standart GPS/GLONASS - 2G/900/1800 - More … GPS/GLONASS - 2G/900/1800 - Iridium/SBD
Power source External 12-36V
Battery 1100 mA
Antenna GPS / IRIDIUM - external, GSM / GPRS - external
Memory 16GB
Q'ty of channels 1 GSM module
Q'ty SIM per channel 2 (different operators)
Connectors SMA female
Datacom GPRS, SMS, SBD
Interface RS-232, RS-485, USB, CAN & K(L)-Line
Dimensions, HWD 103 x 65 x 28 mm
Weight 0.3 kg
Shipment Worldwide
Price 841 $
Other currency 799 ˆ
In stock
Wire Transfer VISA MasterCard

The device NAVISET GT-50 is GPS/GLONASS solution with Iridium embedded for the most demanding users. Designed for use in the control of vehicles, fuel, health, etc.
The device transmits data at any point of the earth, even if there is no connection to GPRS.
News for motor vehicles, which is used in the unstable GSM signal or its absence.

Device NAVISET GT-50 Iridium works with software products Wialon, GPS Lite, GEOSTRON, 1C: ITOB Monitoring and others. If your company is a developer of software platforms for monitoring, we will be happy to provide you with a description our product data transmission protocols to connect.


Key features NAVISET GT50:

  • GPS/GLONASS tracker with Iridium embedded
  • Location of your vehicles
  • Control of fuel consumption
  • Protection of Transport + panic button
  • Voice communication with the driver
  • Voice menu to control external devices (no SD card)
  • A simple version of the standard alarm
  • Pictures with RS232 Video
  • Temperature with 8 sensors
  • The current driver, if more than one person, I-Button
  • The ability to move abroad without GPRS roaming

Main advantages

  • The presence of 2 SIM cards to be confident in the stability of communication with the device and eliminate expensive GPRS roaming when traveling outside the range of the mobile operator.
  • Allows you to connect two parallel digital fuel sender via RS485 interface, summing their values
  • Thanks to the voice menu, you can easily control the engine, perform the speakerphone to the driver, etc.
  • The device founded on the most required functionality while maintaining the lowest prices on the market.
  • Heating of SIM cards to work in the North.
  • Configuration and change the firmware via USB or GPRS connection.
  • Resistance to interference voltage and its multiple exceedance is achieved by using a high-frequency voltage regulator rated at 5A in conjunction with the two-level protection at the input.
  • Monoblock design increases reliability.
  • Use of modern equipment and highly qualified staff will undoubtedly affect the quality of finished products
  • 3 mode of operation to optimize data transfer costs.
  • Long service life thanks to the use of the original element base.
File Title Release Date File Type Size (mb) Action
User Manual GT-20 v1.6 configurator 05-08-2015 Documentation (pdf) 0.89 MB download
User guide for GT series Naviset trackers 01-30-2020 Documentation (pdf) 4.43 MB download
Registration Certificate GT-10 10-19-2013 Documentation (pdf) 0.71 MB download

To access this product file, get partner STE status

File Title Release Date File Type Size (mb) Action
User Manual GT-20 v1.6 configurator 05-08-2015 Documentation (pdf) 0.89 MB download
User guide for GT series Naviset trackers 01-30-2020 Documentation (pdf) 4.43 MB download
Registration Certificate GT-10 10-19-2013 Documentation (pdf) 0.71 MB download

To access this product file, get partner STE status


ParameterValue
Operating temperature range-35...+55 °C
Storage temperature-40...+80 °C
Relative humidity0...90% (0...35 °C); 0...70% (35...55 °C)
Operability (altitude)0-9999 m
Storage
0-10000 m
Redundant power:
Lithium polymer battery; 1100ma
Battery life (continuous)Depends on the configuration of the device; average 8h
External powerup to 35V; Protection against any impulse surges in the vehicle electrical system
Dimensions 103 x 65 x 28 mm
Weight300g
Key Features:
Antenna GLONASS/GPSExternal
Antenna GSM/GPRSExternal
ConnectorExternal
Inserting the SIM cardExternal SIM holders
Analog / digital inputs8 universal 0-27 V; of which 2 frequency, 2 pulse
Connection of the cameraRS-232
"Black Box"yes, built-in flash memory of 16 MB
Voice menu for control and communication with the driveryes
SIM card q'ty2 pcs
RS485 interface1 (TTL or RS)
RS232  interface2 pcs
1 wire  interface1 (up to 8x temperature sensors & I-Button)
Speakerphoneyes
CAN-Speakerphone1 (FMS)
Autoinformeryes
Transistor outputs4 pcs
USB-interfaceSetting up, diagnostics, flashing device
Warranty1 year from date of purchase or more
File Title Release Date File Type Size (mb) Action
User Manual GT-20 v1.6 configurator 05-08-2015 Documentation (pdf) 0.89 MB download
User guide for GT series Naviset trackers 01-30-2020 Documentation (pdf) 4.43 MB download
Registration Certificate GT-10 10-19-2013 Documentation (pdf) 0.71 MB download

To access this product file, get partner STE status

File Title Release Date File Type Size (mb) Action
User Manual GT-20 v1.6 configurator 05-08-2015 Documentation (pdf) 0.89 MB download
User guide for GT series Naviset trackers 01-30-2020 Documentation (pdf) 4.43 MB download
Registration Certificate GT-10 10-19-2013 Documentation (pdf) 0.71 MB download

To access this product file, get partner STE status

Additional Product Information
CAN and K (L) data bus
2 Sim cards
I-Button mode
RS485 port (TTL or RS)
